    3M 468MP Adhesive Transfer Tape

    Manufacturer: 3M
    Adhesive tape with double-sided adhesive, thin To be used for bonding workpieces or two-sided materials together Can be used with easily attached surfaces or difficult surfaces Can be attached to various types of surfaces such as glass, plastic, rubber, wood, paper, steel, concrete, foam, polycarbonate and others
    SKU: ม้วน/Roll
    *
    banner
    ฿205.00 excl tax
    i h

    3M™ High Performance Acrylic Adhesive 200MP is a popular choice for graphic attachment and general industrial joining applications. It provides outstanding adhesion to metal and high surface energy plastics. This adhesive provides some initial repositionability for placement accuracy when bonding to plastics. It also performs well after exposure to humidity and hot/cold cycles.

    • Up to 400°F short-term heat resistance
    • Excellent solvent resistance
    • Excellent shear strength to resist slippage and edge lifting
    Attribute Name
    Value
    Adhesive Type
    3M™ High Performance Acrylic Adhesive 200MP, Acrylic, High Performance Acrylic
    Assembly Type
    Gasket Attachment, Large Surface Lamination, Mounting and Trim Attachment
    Brand
    3M, 3M™
    Color
    Clear
    Face-Side Adhesive Thickness
    5 mil
    Face-Side Adhesive Thickness (metric)
    0.13 mm
    Face-Side Adhesive Type
    3M™ High Performance Acrylic Adhesive 200MP
    Indoor/Outdoor
    Both
    Industries
    Aerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial,
    Medical, Metalworking, Military, Military & Government, MRO, Packaging,
    Point of Purchase, Print, Retail, Signage, Specialty Vehicle, Transportation, Woodworking
    Length
    10 Linear Yard, 120 Linear Yard, 180 Linear Yard, 3 Linear Yard, 360 Linear Yard, 60 Linear Yard
    Length (Metric)
    109.72 m, 109.73 m, 164.59 m, 165.59 m, 2.74 m, 329.18 m, 54.86 m, 9.14 m
    Master Size Length
    180 Linear Yard
    Master Size Width
    48 Inch
    Maximum Operating Temperature (Celsius)
    204 Degree Celsius
    Maximum Operating Temperature (Fahrenheit)
    400 Degree Fahrenheit
    Minimum Operating Temperature (Fahrenheit)
    -40 Degree Fahrenheit
    National Stock Number
    7510014365626, 7510016085729, 7510016191444
    Primary Liner
    58# Polycoated Kraft Paper (PCK)
    Primary Liner Color
    Tan
    Primary Liner Thickness
    4.2, 4.2 mil
    Product Form
    Roll, Sheet
    Shelf Life
    18 months from date of shipment
    Shelf Life in Months (from date of manufacture)
    18
    Size
    Custom
    Specifications
    GM
    Substrate 1
    Glass, Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated
    - Copper
    - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber -
    Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide
    - Polystyrene - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon)
    Substrate 2
    Glass, Glass (Inked Glass - Ceramic), Metal (Aluminum - Powder Coated
    - Copper
    - Stainless Steel - Zinc/Galvanized), Plastics/Composites (ABS - Carbon Fiber
    - Acrylic - Fiberglass - Polycarbonate - Polyester - Polyimide - Polystyrene
    - Rigid Vinyl), Plastics/Composites (Glass Filled Nylon)
    Substrates
    Glass, HSE Plastics and Glass, Metal, Paint, Smooth
    Tape Thickness
    5 Milli-inch (mil)
    Thickness
    5.2 mil
    Thickness (Metric)
    0.13 mm
    Volatile Organic Compounds (VOCs)
    See Safety Data Sheet, Regulatory Data Sheet
    Width
    0.5 Inch, 0.75 Inch, 1 Inch, 10 Inch, 11.75 Inch, 12 Inch, 12.5 Inch,
    13 Inch,
    13.5 Inch, 16 Inch, 18 Inch, 2 Inch, 20 Inch, 23.5 Inch, 23.75 Inch, 24 Inch,
    27 Inch, 3 Inch, 4 Inch, 48 Inch, 54 Inch, 59 Inch, 6 Inch, 60 Inch, 9 Inch,
    9.6 Inch, 9.75 Inch
    Width (Metric)
    101.6 mm, 12.7 mm, 1219.2 mm, 1371.6 mm, 1498.6 mm, 152.4 mm, 1524 mm,
    19.05 mm, 228.6 mm, 243.84 mm, 247.65 mm, 25.4 mm, 254 mm, 298.45 mm,
    304.8 mm,
    317.5 mm, 330.2 mm, 342.9 mm, 406.4 mm, 457.2 mm, 50.8 mm, 508 mm,
    596.9 mm, 603.25 mm, 609.6 mm, 685.8 mm, 76.2 mm
